| 型号 Model |
粉碎能力 Crushing capacity |
功率Kw/Hp Power |
入口尺寸 Into size(mm) |
固定刀(PCS) Stationary Cutter |
旋转刀(PCS) Rotary Cutter |
刀具尺寸 Cutter Size(mm) |
机械尺寸 Machine SizeL× W× H(mm) |
机器重量 Weight(kg ) |
| GSCY-30 | 90-120 | 2.2/3.0 | 180× 160 | 2 | 9 | 180× 160 | 695 × 525×975 | 250 |
| GSCY-50 | 100-160 | 4.0/5.0 | 290× 220 | 2 | 15 | 275× 200 | 982× 666× 1088 | 350 |
| GSCY-100 | 150-400 | 7.5/10.0 | 400 × 250 | 2 | 21 | 385 × 240 | 1105× 850× 1220 | 740 |
| GSCY-150 | 300-600 | 11.0/15.0 | 460 × 300 | 2 | 24 | 440×280 | 1400× 1010× 1500 | 1000 |
| GSCY-200 | 500-800 | 15.0/20.0 | 515× 330 | 2 | 27 | 495 × 300 | 1400× 1010× 1500 | 1300 |
| GSCY-300 | 700-1000 | 22.0/30.0 | 550× 440 | 2 | 30 | 550× 320 | 1500× 1160× 1735 | 1700 |
| GSCY- 500 | 1500-1800 | 37.0/50.0 | 720 × 500 | 2 | 27 | 715 × 395 | 1793× 1420× 2071 | 3200 |
| GSCY-750 | 1500-2400 | 55/75 | 940 × 630 | 4 | 36 | 940× 510 | 2098× 1715×2416 | 3815 |
| GSCY-1000 | 2600-3600 | 75/100 | 1100 × 630 | 4 | 42 | 1096× 510 | 2098× 1871 ×2416 | 4215 |
